NP 1 EC ( SAP 205 16 ) - PILLOW BLOCK HOUSING UNIT WITH A 1 INCH BORE - TR BRAND
Cast Iron Two Bolt Pillow Block Housing Unit fitted with flat back bearing insert with Eccentric collar lock from our TR range.
- UnitsPer unit
- 1 - 4£33.46 (£40.15 inc VAT)
- 5 - 9£31.78 (£38.14 inc VAT)
- 10 +£30.12 (£36.14 inc VAT)
- Bulk Order PricesENQUIRE
Specifications for NP 1 EC ( SAP 205 16 ) - Pillow Block Housing Unit with a 1 inch bore - TR Brand | |
| Reference | NP 1 EC |
| Brand | TR |
| Inside Diameter | 1" |
| Bolt | M10 |
| Weight (KG) | 0.81 |
Schematic for NP 1 EC ( SAP 205 16 ) - Pillow Block Housing Unit with a 1 inch bore - TR Brand | |
| A | 38mm |
| B1 | 30.9mm |
| H | 36.5mm |
| H0 | 71mm |
| H1 | 15mm |
| J | 105mm |
| KG | 0.81 |
| L | 140mm |
| N | 13mm |
| N1 | 19mm |
| S | 7.5mm |
